Oil burners One stage BENTONE B2 Classic
Oil burners One stage BENTONE B2 Classic is a burner with a one-stage combustion system, making it convenient to use and allowing for adjustable flame levels according to job requirements. The single-stage combustion system simplifies maintenance and ensures ease of operation. The BENTONE B2 is known for its durability and suitability for various environments.
Oil burners One stage BENTONE B2 Classic
Available with or without preheater. Easy accessible for service. Quiet in operation. High efficiency. Equipped with standard components when looking to control box, transformer and oil pump.
Oil Burner
– Energy saving and compatible with environmental requirements
– Quiet in operation and designed for easy maintenance
– Reliable and trouble free
– Designed and developed to meet the European standard EN 267
– Fully closing air damper saves energry
– Electronic transformer ensures a safer start and operation
– Plug-in contact facilitates the installation and service. Eurostecker integrated
| Type | B2 Classaic | ||||||
| Model | B2S | B2SV | B2KS | B2KSV | B2KA | B2KAV | |
| Capacity | kg/h | 3.1-8.2 | 3.9-11.1 | 2.4-9.0 | |||
| kW | 15.0-42.0 | 14.2-36.3 | 28.5-106.7 | ||||
| Motor | V/Hz/W | 230/50/110 | |||||
| Cntrol box | LOA24 | ||||||
| Oil preheater | . | . | . | ||||
| Fuel pump | BFP41 L3 | ||||||
| Adjustable burner head | . | ||||||
| Gross weight | kg c. | 12 | |||||
| Volume | m³ c. | 0.05 | |||||
