Oil burners Three stage BENTONE B55
Oil burners Three stage BENTONE B55 is a burner designed with a three-stage combustion system, allowing for flexible adjustment of flame levels according to job requirements. The three-stage system helps to reduce energy consumption efficiently and ensures a balanced and efficient combustion process. The BENTONE B55 is known for its durability and suitability for various environments.
Oil burners Three stage BENTONE B55
Available in 2-stage and 3-stage versions.
Hydraulic adjustment of the nozzle assembly is optional. Quiet in operation. A soft pulsation free start. Wide adjustment range, high efficiency with constant combustion values. Energy saving.
Oil Burner
– Energy saving and compatible with environmental requirements
– Designed for easy regulation and maintenance
– Reliable and trouble free
– Designed and approved in accordance with the European standard EN 276
– Suitable for Hight Resistance Boiler
– 2 or 3-stage
– Industry standard components easily available
– Available with hydraulic air adjustment or airdamper motor
– Plug-in contact facilitates the installation
| Type | B55-2 | B55-2H | B55-2R | B55-3R | |
| Capacity | kg/h | 14-67 | 14-67 | 14-67 | 14-64 |
| kW | 166-795 | 166-795 | 166-795 | 166-760 | |
| Motor | V/Hz/W | 230-400/50/750 | |||
| Cntrol box | Siemens | ||||
| Fuel pump | Danfoss | ||||
| Thermostat RT16 | . | ||||
| Gross weight | kg c. | 50 | |||
| Volume | m³ c. | 0.3 | |||
