Chemical Pump LITTLE GIANT 3-MD-SC Series
The Little Giant MD-SC model has a chemical leak proof seal. Designed for non-dip applications The pump is a spiral shaped steel body and the propeller is made of glass fiber reinforced polypropylene for excellent chemical resistance. And the ring is 99.5% pure alumina, preventing wear and trouble-free service The pump head can rotate easily.Cleaning or servicing without special tools The axle supports both ends to prevent impeller damage Between the start and stop of the pump
Facebook
Twitter
Email
Print
Chemical Pump LITTLE GIANT 3-MD-SC Series
Fluid System Design Parameters*
- Fluid temperature – Up to 150°F (65°C)
- Fluid specific gravity – Up to 1.1
- Fluid viscosity – Up to 100 SSU (20 CPS)
- Ambient air temperature – Up to 77°F (25°C)
- For chemical resistance of pump wetted components refer to Chemical Resistance Chart.
SPECIFICATIONS DATA LITTLE GIANT 3-MD-SC Series
| Model | Item No. | Intake Size | Discharge Size | Listing(s) | HP | Volts | Hertz | Amps | Watts |
| 3-MD-SC | 581503 | 3/4″ FNPT | 1/2″ MNPT | UR/C-CSA | 1/12 | 115 | 60 | 2.4 | 190 |
| 3-MD-SC | 581513 | 3/4″ FNPT | 1/2″ MNPT | UR/C-CSA | 1/13 | 230 | 60 | 1.2 | 190 |
| 3-MD-SC | 581576 | 3/4″ FNPT | 1/2″ MNPT | UR | 1/14 | 230 | 50 | 1.7 | 205 |
| 3-MD-SC | 581597 | 3/4″ FNPT | 1/2″ MNPT | Pump Head Less Motor | |||||
| Model | Item No. | Performance (GPH @ Head) | Shut Off | Power | Weight | |||||
| 1′ | 3′ | 6′ | 9′ | 15′ | Feet | PSI | Cord (ft.) | (lbs.) | ||
| 3-MD-SC | 581503 | 750 | 710 | 665 | 600 | 425 | 21.9 | 9.5 | 6 | 8.5 |
| 3-MD-SC | 581513 | 750 | 710 | 665 | 600 | 425 | 21.9 | 9.5 | 6 | 8.5 |
| 3-MD-SC | 581576 | 625 | 570 | 520 | 430 | – | 15 | 6.5 | 6 | 7.7 |
| 3-MD-SC | 581597 | Pump Head Less Motor | 0 | 6 | 2 | |||||
