Metering Pump DOSSER MSJ1 Series
DOSSER MSJ series solenoid diaphragm metering pump is effective and reliable digital pump. The solenoid shaft is sucked by the magnetic wire and pushed back by the spring, which makes the diaphragm in the dosing head suck and discharge. The check valves which with double balls prevent backflow when pumping.The precise dosing can be controlled both by the stroke length and stroke speed manually. The capacity range is from 1.0l/h to 15l/h at a back pressure from 15 bars to 1bar. All most any chemical with low viscosity can be dosed with MSJ solenoid diaphragm metering pump.It is an economical meterng pump widely used in dosing applicaitons.
Metering Pump DOSSER MSJ1 Series
Manual Solenoid Diaphragm Metering Pump
DOSSER MSJ1 Series Applications:
- Potable water treatment: Metering of disinfectants
- Cooling circuits: Metering of corrosion inhibitors and biocides
- Waste water treatment: Metering of flocculants
- Paper industry: Metering of additives
- Plastics production: Metering of additives
DOSSER MSJ1 Series Features:
- Manual flow control by both stroke length and stroke speed;
- Wear-free solenoid driving with no bearing;
- Compact modular design( liquid end, drive and electronic board are modular, easy for replacement) ;
- Intelligent display the stroke speed in percentage;
- Check valve assemblies are with two balls and are designed for easy maintenance;
- Accessories are included: hose,injection valve,foot valve,ceramic weight;
DOSSER MSJ1 Series Materials:
- Pump Head: PVC, PVDF, SS304, SS316
- Diaphragm: Composite PVDF diaphragm
- Check Valve Body: PVC, PVDF, SS304, SS316 (same as pump head selection)
- Valve Ball: Ceramic, SS304
- Valve Seat: PVDF, SS316
- Suction and Discharge Tubing: PE
Connection Type:
PE hose for all models
Voltage Supply:
220V 50/60Hz or 110V 50/60Hz
Specifications Metering Pump DOSSER MSJ1
| Model | Flow | Pressure | Stoke Control | Puise frequency | Callber |
| L/H | Bar | % | Storke/min | mm | |
| DOSSER MSJ10110 | 1 | 10 | 20-100 | 60-140 | 5 |
| DOSSER MSJ10408 | 3.8 | 7.6 | 20-100 | 60-140 | 5 |
| DOSSER MSJ10505 | 5 | 5 | 20-100 | 60-120 | 5 |
| DOSSER MSJ10804 | 7.6 | 3.4 | 20-100 | 60-160 | 5 |
| DOSSER MSJ11002 | 10 | 2 | 20-100 | 60-180 | 5 |
| DOSSER MSJ11202 | 12 | 1.5 | 20-100 | 60-140 | 5 |
| DOSSER MSJ11501 | 15 | 1 | 20-100 | 60-160 | 5 |
