Electric Wire Rope Hoist PA 8/4 series

Electric Wire Rope Hoist PA 8/4 series

Electric Hoist PA series has compact and exquisite appearance and has the features of easy installation, security and reliability. It is the important tool for hoisting in workshops, household garages and warehouses etc.It adopts single-phase power and is widely used.

Category Tags , , , , ,
ขอใบเสนอราคา/Request a quote
Facebook
Twitter
Email
Print

Electric Wire Rope Hoist PA 8/4 series

FEATURES

  • Motor With automatic bracke system and thermal protection function.the thermal protection terminal will be automatically disconnected to protect the motor when the motor becomes overheated.
  • Lower Limit Lever When the wire rope is going doen to the position we designed.the wire rope will automatically act the limit lever also prevent the wire rope improperly winding in the reverse direction on the drum.
  • Upper Limit Lever When the load is lifting at the position we designed.the counter weight and limit stopper will automatically act the upper limit lever to stop the hoist
  • Wire rope Structure and anti-twist aircraft rope.with breaking force up to at lease 4 time than the rated lifting capacity.
  • Pulley hook Included in the product.when the load exceeds the lifting capacity of the single hook but less than max.lifting capacity.use the pulley hook to lift the load
  • Power plug All of plug styles are available in all over countries and regions and approved by VDE ro UL



Specification PA 8/4 series

Key Specifications/Features:
• The emergency stop switch
• Upper limit function
• Protection class IP54
• Insulation class B
• Group of mechanisms M1
• Work Duty: S3-25%-10min
• Rated Volt: 220/230V ~ 50Hz
• Rated Current: 1.95A
• Input Power: 220W
• Lifting Weight:50kg(Single-line),100kg(Double-line)
• Lifting Height:8m(Single-line),4m(Double-line)
• Lifting Speed:8m/min(Single-line),4 m/min(Double-line)
• Diameter of wire rope:2mm
• Tensile strength of wire rope ≧ 1770N/mm2
Logistic Information:
• G.W./N.W.: 20.5/19.5kg
