| Standard | Mounting | Voltage | Enclosure | Motor type | Description |
| NEMA | Horizontal | LV | TEFC | AEEAGD | Crusher Duty Motors |
| ODP | ASFAFP | Oil Well Pump Motors | |||
| TEFC | AEEAFP | ||||
| AEHECW | Wash Down Duty Motors | ||||
| (Cast Iron Frame) | |||||
| AEGACW | Wash Down Duty Motors (Rolled Steel Frame) |
||||
| AEGAFW | |||||
| AETECW | |||||
| AEGECW | |||||
| AEGEFW | |||||
| TENV | AENCFW | ||||
| AENCCW | |||||
| Vertical | AENVCW | ||||
| TEFC | AETACW | ||||
| IEC,BS, AS,JIS, JEC,CNS |
Horizontal | AEEBXC | Non Sparking Fan | ||
| Vertical | AEVBXC | ||||
| Horizontal | AEEBYH | Smokespill Motors | |||
| Vertical | AEVBYH | ||||
| Horizontal | AECP/AEPP | Pole Change Motors | |||
| AEEFSA | Double Shaft Motors | ||||
| AEMC | Cooling Fan Motors | ||||
| Vertical | AEVFLR | Long Shaft Motors |
Wash Down Duty Motors
Low Voltage Squirrel Cage Motors
Foot Mounted with C-Face Flange
TEFC, NEMA T-Frame Design B or C
Cast Iron Frame
Output 3 ~ 10 HP
Pole (Speed) 2, 4
Voltage 230/460V
Frequency (Hz) 60
Frame Size 182TC ~ 215TC
Protection Enclosure: IP 55
Design Standards: NEMA MG-1, MG-13
Environment: non-hazardous, high humidity and regularly exposed to high pressure water wash down.
Stator Insulation: Class F insulation, B rise SF 1.15
Wash Down Duty Motors
TEFC T-frame, Design B
Output 1/2 ~ 10HP
Pole (Speed) 2 ~ 4
Voltage 230/460V (usable on 208V at 1.0 SF)
Frequency (Hz) 60
Frame Size 56C ~ 215TC
Protection Enclosure TEFC, IP 55
Design Standards: NEMA MG-1, MG-13
Environment: non-hazardous, high humidity and regularly exposed to high pressure water wash down.
Stator insulation: Class F Insulation, B rise SF 1.15.
External surface: rust-proof primer finished with USDA approved white epoxy paint.
Test procedure: ANSI/IEEE-112 Method B and full voltage measuring starting performance.
Wash Down Duty Motors
3-Phase Induction Motors
TEFC T-frame, Design B
Output 1/2 ~ 2HP
Pole (Speed) 2 ~ 4
Voltage 230/460V (usable on 208V at 1.0 SF)
Frequency (Hz) 60
Frame Size 56C ~ 145TC
Protection Enclosure TEFC, IP 44
Design Standards: NEMA MG-1, MG-13
Environment: non-hazardous, high humidity and regularly exposed to high pressure water wash down.
Stator insulation: Class F Insulation, B rise SF 1.15.
Wash Down Duty Motors
Low Voltage Squirrel Cage Motors
TENV, NEMA T-Frame Design B, Rolled Steel Frame
Output 1/2 ~ 10 HP
Pole (Speed) 2, 4
Voltage 230/460V
Frequency (Hz) 60
Frame Size 56C ~ 215
Protection Enclosure: IP 55
Design Standards: NEMA MG-1, MG-13
Environment: non-hazardous, high humidity and regularly exposed to high pressure water wash down.
Stator Insulation: Class F insulation, B rise SF 1.15
Non-Sparking 3-phase Induction Motors
TEFC T-Frame Design B or N
Output 1 ~ 250HP (0.75 ~ 185 KW)
Pole (Speed) 2 ~ 8
Voltage below 690V
Frequency (Hz) 50, 60
Frame Size 80~315MC
Protection Enclosure IP 55
Design Standards: BS 5000 Part 16; BS EN60034, BS 4999
Environment: Zone 2, Group II Hazardous
Stator insulation: Class F Insulation
AEPP variable torque
Pole (Speed) Change Induction Motors
TEFC, Squirrel Cage
(High Voltage & Output 15,000HP max. are available per request.)
Output 0.25/0.125 ~500/250 HP (for constant torque output)
0.25/0.25 ~ 400 HP ¡@¡@(for constant HP output)
Pole (Speed) 2/4 ~ 8/16
Voltage 220V, 380V, 440V
Frequency (Hz) 50, 60
Frame Size 63 ~ 450MB
Protection Enclosure IP 44
Design Standards: IEC, BS, JEC
Environment: non-hazardous
Stator insulation: Class B or F Insulation
AEVFLR, AEVFLS, AEUE8R
Output 1/2 ~ 100HP
Pole (Speed) 2 ~ 8
Voltage 220V, 380V, 440V, 460V
Frequency (Hz) 50, 60
Frame Size 63 ~ 250M
Protection Enclosure IP 44 (IP54, IP55 Options)
Output 1/4 ~ 270HP
Pole (Speed) 2 ~ 8
Voltage below 600V
Frequency (Hz) 50, 60
Frame Size 63 ~ 315M
Protection Enclosure IP 54
Output 1/8 ~ 10 HP
Pole (Speed) 4 ~ 10
Voltage below 600V
Frequency (Hz) 50, 60
Frame Size 63 ~ 132
Protection Enclosure IP 54
High Temperature-Resistant 3-phase induction motors
BS Design Low Voltage Squirrel Cage
WFR approved.
Output 1 ~ 250 HP, 45 ~ 185KW
Pole (Speed) 2 ~ 8
Voltage below 600V
Frequency (Hz) 50, 60
Frame Size 80 ~ 315MB
Protection Enclosure IP 54
Design Standards: Meet BS 7346 Part 2, 1990 Specification.
Environment:
Stator insulation: Class H insulation
Temp/Time: 300¢J, 60 min. D class
400¢J, 120 min. E class
Low Voltage Oil Well Pump Motors, Triple Rated,
TEFC, NEMA Design D, Cast Iron Frame
Output 7.5 ~ 50 HP
Pole (Speed) 6
Voltage 460V, 575V
Frequency (Hz) 60
Frame Size 250T ~ 400T
Protection Enclosure IP 54
Design Standards: NEMA MG-1, MG-13
Environment: non-hazardous
Stator Insulation: Class F insulation, F rise at SG 1.15 or SF 1.0
Fully garded with Rodent screens.
Oversized bearings selected for Belt-drive application.
Grounding Terminals on Frames and Inside Conduit Box.
Thermal Protectors Embedded in Winding in each phase.
Stainless Steel Nameplate.
Low Voltage Oil Well Pump Motors
ODP, NEMA Design D, 5 ~ 8% slip,
Cast Iron Frame, Design D
Output 5 ~ 150 HP
Pole (Speed) 6
Voltage 230/460/796V
Frequency (Hz) 60
Frame Size 215T~445T
Protection Enclosure IP 22
Design Standards: NEMA MG-1, MG-13
Environment: non-hazardous
Stator insulation: Class F Insulation, 1.15 SF.
Cast Iron Frame, End Brackets & Oversized Conduit box.
Fully guarded with Rodent screens.
Oversized bearings selected for Belt-drive application.
Grounding Terminals on Frames and Inside Conduit Box.
Thermal Protectors Embedded in Winding in each phase.
Standard 3-Phase Induction Motors
Low Voltage Squirrel Cage
Output 200 ~ 500 HP
Pole (Speed) 2~8
Voltage 460V, 575V
Frequency (Hz) 60
Frame Size 5007C ~ 5808C
Protection Enclosure IP55
Design Standards: NEMA MG-1, MG-13
Environment: non-hazardous
Stator insulation: Class F Insulation, 1.15 SF.
