Pressure Switch DANFOSS model KP 36 are used for regulating, monitoring and alarm systems in the industry. They can also be used to start/stop compressors and fans for air-cooled condensers. They are suitable for single pole switch changeover (SPDT) and can control single phase AC motor of up to 2 kW directly.
DANFOSS pressure switch model KP 36 is a pressure control switch designed by the brand DANFOSS. It functions as a NO (Normally Open) or NC (Normally Closed) contact type. This pressure switch aids in controlling systems where pressure fluctuates above or below a predefined set point. It’s engineered to regulate pressure in water, air, or gas systems, making it compatible with booster pumps, air compressors, water pumps, and similar systems. It’s space-efficient, easy to use, and capable of withstanding strong pressure shocks. Additionally, it can directly control electric motors up to 2 kW in size.
Feature DANFOSS pressure switch model KP 36
Code : 060-110891
Regulating range
Differential : 2-6 bar
Reset : auto
Connection size : G ¼ A
| Type | Range (psig) | Differential (psi) | Reset | Pressure Connection | Max.operating pressure (psig) | Min.burst pressure (psig) |
|---|---|---|---|---|---|---|
| KP 36 | 15 - 150 | Oct-58 | Automatic | ¼" 18 NPT | 245 | 1015 |
