Submersible Pump FLYGT 9800 WS Series
- Flows from 10,000 to 220,000 gpm (2,000 to 50,000 m3/h)
- Heads from 10 to 600′ (3 to 175 m)
- 24 to 66 inch Discharge (610 to 1676 mm)
- 245 to 880 RPM
Facebook
Twitter
Email
Print
Submersible Pump FLYGT 9800 WS Series
PROVEN PERFORMANCE WITH OVER 130 YEARS OF EXPERIENCE: HIGH EFFIENCIES, LOW ENERGY COSTS AND WIDE OPERATING RANGE
- A wide range of available hydraulics enables customization of pump selections to maximize pumping efficiencies. Pump efficiencies up to 91% save money on operating costs.
- Pumps are available in a wide variety of metallurgies to suit the particular application.
- Can be manufactured to NSF 61 compliance for drinking water.
- Horizontal or vertical mounting saves space and reduces station footprint.
- Choice of side suction or bottom suction allows application flexibility and lowers the construction costs.
- Easy to install and service – flanges on common centerlines simplify piping layouts; axially split casing allows for ease of maintenance.
- Renewable impeller and casing wear rings permit easy maintenance of proper running clearances that will result in increased impeller service life and sustained operational efficiency.
- Heavy duty design double suction impellers and dual volute casings (most sizes) minimize bearing loads and shaft deflections, therefore providing long term trouble free operation.
- With full scale performance testing capabilities up to 520,000 GPM (120,000 m3/hr) or 9850 HP (7350 kW) the performance of each pump can be accurately certified before it leaves the factory.
- Readily-accessible service centers, technical know-how, spare parts, and support to ensure minimal downtime costs and the most cost-effective operations.
