MITSUBISHI WCL Series

Centrifugal Pump MITSUBISHI WCL Series

Centrifugal Pump MITSUBISHI WCL Series  are centrifugal pumps. The amount of water Suitable for agriculture industrial sector and the desired quantity of water. Both standard and flange with all five models including WCL-755S, WCL-1105S, WCL-1505S, WCL-2205FS and WCL-3705FS Range 4 meters deep, maximum speed of 3000 rpm.



Category Tags , , , , , ,
ขอใบเสนอราคา/Request a quote
Facebook
Twitter
Email
Print

Centrifugal Pump MITSUBISHI WCL Series

Highlights of the water Centrifugal Pump Mitsubishi WCL Series WCL-755S, WCL-1105S, WCL-1505S, WCL-2205FS, WCL-3705FS.

  •  large water pump Suitable for agricultural work Industrial sector And public utilities
  • Suitable for applications that require a lot of water. With both standard type and flange
  • Using Mitsubishi electric motor which has high working efficiency The pump is made of cast iron. And the pump shaft is made of SUS304 stainless steel
  • brass propeller Closed type, high pumping efficiency
  • Leak proof with mechanical seal, ceramic and graphite Which is waterproof and has a long service life\
  • Closed squirrel cage induction motor Fan cooled – IP55 protection standard. Used to report Class F electrical insulation for
  • Continuous use And the motor shaft is one piece with the pump shaft



SPECIFICATIONS DATA MITSUBISHI WCL SERIES

Model Discharge HP Voltage
WCL  – 1105S 2 1/2″ x 2 1/2″ 1.5 220
WCL  – 1505S 3″ x 3″ 2 220
WCL  – 1505T 3″ x 3″ 2 380
WCL  – 2205S 3″ x 3″ 3 220
WCL  – 2205T 3″ x 3″ 3 380
WCL  – 2205FS 3″ x 3″ 3 220
WCL  – 2205FT 3″ x 3″ 3 380
WCL  – 3705FS 3″ x 3″ 5 220
WCL  – 3705FT 3″ x 3″ 5 380
WCL  – 5505FT 2 1/2″ x 2″ 7.5 380
WCL  – 7505FT 2 1/2″ x 2″ 10 380
WCL  – 11005FT 2 1/2″ x 2″ 15 380
WCL  – 15005FT 2 1/2″ x 2″ 20 380



DIMENSIONS DATA MITSUBISHI WCL SERIES TABLE 1

Dimension ปั๊มหอยโข่ง MITSUBISHI WCL Series

MODEL BORE SIZE (Inch) DIMENSIONS (mm.) WEIGHT (kg.)
1Φ 3Φ BS1 BS2 a f hi h2 n1 n2 w1 w2 s 1Φ 3Φ
WCL-755S – 21/2″ 2 1/2″ 44 359.5 132 324 190 240 47.0 – 15 21.5 –
WCL-1105S – 21/2″ 2 1/2″ 44 404.0 132 324 190 240 47.0 – 15 25.5 –
WCL-1505S/2205S WCL-1505T/2205T 3″ 3″ 45 460.5 132 324 190 240 23.5 70 15 46.0 44.6
WCL-2205FS WCL-2205FT 3″ 3″ 80 501.0 132 292 190 240 58.5 70 15 55.8 54.4
WCL-3705FS WCL-3705FT 2 1/2″ 2″ 100 488.5 160 340 212 265 65.0 70 15 57.5 56.1



DIMENSIONS DATA MITSUBISHI WCL SERIES TABLE 2

Dimension ปั๊มหอยโข่ง MITSUBISHI WCM/WCL Series (1)

MODEL BORE SIZE (Inch) DIMENSIONS (mm.) WEIGHT (kg.)
1Φ 3Φ BS1 BS2 a f hi h2 n1 n2 w1 w2 s 10 30
WCL-755S – 21/2″ 2 1/2″ 44 359.5 132 324 190 240 47.0 – 15 21.5 –
WCL-1105S – 21/2″ 2 1/2″ 44 404.0 132 324 190 240 47.0 – 15 25.5 –
WCL-1505S/2205S WCL-1505T/2205T 3″ 3″ 45 460.5 132 324 190 240 23.5 70 15 46.0 44.6
WCL-2205FS WCL-2205FT 3″ 3″ 80 501.0 132 292 190 240 58.5 70 15 55.8 54.4
WCL-3705FS WCL-3705FT 2 1/2″ 2″ 100 488.5 160 340 212 265 65.0 70 15 57.5 56.1
