Engine Pump Clear Water Pump KOSHIN SEH-X Series
Model. SEH-50X, SEH-80X
Engine Pump Clear Water Pump 2-4 Inch Pump Honda SEH Series (2″ 3″ 4″) SEH-50X-BAE, SEH-50X-BBS, SEH-50X-BFY, SEH-80X-BAC, SEH-80X-BBU
Features
- Impellers and Volutes are Constructed of Cast Iron for Durability and Long Operating Life
- Pump Housings are Made of Die Cast Aluminum for Strength, Weight Reduction, and Portability
- Rugged Powder Coated Steel Roll Cages
- Reliable Koshin Engines with Low Oil Shut Off
- Self-Priming up to 26’ of Suction Lift
- Maximum Head up to 90’
- Three Year Limited Warranty on Engines and Pumps
APPLICATIONS
- Agricultural
- Construction
- Municipal / Industrial
- irrigation
- Pools and Central Clear water Transfer.
- Irrigation of rice fields
- Irrigation with sprinkler systems
- Gardening/fruit growing
- Pump water from wells
- Filling of water reservoirs
- Filling or draining water from ponds
- Filling or draining water from fish farms
- Washing livestock, stables or farm equipment
- Pumping of water with solid particles up to 3 mm
SPECIFICATIONS
| Model | SEH-50X-BAE | SEH-50X-BBS | SEH-50X-BFY | SEH-80X-BAC | SEH-80X-BBU | |
|---|---|---|---|---|---|---|
| PUMP | Connection Dia | 50 mm (2″) | 50 mm (2″) | 50 mm (2″) | 80 mm (3″) | 80 mm (3″) |
| Connection Thread | Outer Pipe Thread BSP or NPT | Outer Pipe Thread BSP or NPT | Outer Pipe Thread BSP or NPT | Outer Pipe Thread BSP or NPT | Outer Pipe Thread BSP or NPT | |
| Total Head | 30 m (98 ft) | 27 m (88 ft) | 27 m (88 ft) | 27 m (88 ft) | 26 m (85 ft) | |
| Delivery Volume | 600 L/min (158 USG/min) | 640 L/min (169 USG/min) | 640 L/min (169 USG/min) | 1100 L/min (290 USG/min) | 930 L/min (246 USG/min) | |
| Max. Suction Lift | 8 m (26 ft) | 8 m (26 ft) | 8 m (26 ft) | 8 m (26 ft) | 8 m (26 ft) | |
| Impeller | FC200 | FC200 | FC200 | FC200 | FC 200 | |
| Volute Casing | ADC12 | FC200 | FC200 | FC200 | ADC 12 | |
| ENGINE | Type | Forced Air-cooled 4-stroke Gasoline Engine | Forced Air-cooled 4-stroke Gasoline Engine | Forced Air-cooled 4-stroke Gasoline Engine | Forced Air-cooled 4-stroke Gasoline Engine | Forced Air-cooled 4-stroke Gasoline Engine |
| Model | Honda GX120 | Honda GX120 | Honda GX160 | Honda GX160 | Honda GX160 | |
| Displacement | 122 cc | 122 cc | 163 cc | 163 cc | 163 cc | |
| Rated Output | 2.1 kW (2.9 PS) / 3600 rpm | 2.1 kW (2.9 PS) / 3600 rpm | 2.9 kW (3.9 PS) / 3600 rpm | 2.9 kW (3.9 PS) / 3600 rpm | 2.9 kW (3.9 PS) / 3600 rpm | |
| Max. Output | 2.4 kW (3.3 PS) / 3600 rpm | 2.4 kW (3.3 PS) / 3600 rpm | 3.6 kW (4.9 PS) / 3600 rpm | 3.6 kW (4.9 PS) / 3600 rpm | 3.6 kW (4.9 PS) / 3600 rpm | |
| Fuel | Automotive Unleaded Gasoline | Automotive Unleaded Gasoline | Automotive Unleaded Gasoline | Automotive Unleaded Gasoline | Automotive Unleaded Gasoline | |
| Fuel Tank Capacity | 2.0 L (0.53 USG) | 2.0 L (0.53 USG) | 3.1 L (0.82 USG) | 3.1 L (0.82 USG) | 3.1 L (0.82 USG) | |
| Continuous Operating Time | Approx. 2 hrs | Approx. 2 hrs | Approx. 2 hrs | Approx. 2 hrs | Approx. 2 hrs | |
| Starting Method | Recoil Starter | Recoil Starter | Recoil Starter | Recoil Starter | Recoil Starter | |
| Standard Accessories | 1 Strainer, 2 Hose Couplings, 3 Hose Bands, 1 Engine Tool Set | 1 Strainer, 2 Hose Couplings, 3 Hose Bands, 1 Engine Tool Set | 1 Strainer, 2 Hose Couplings, 3 Hose Bands, 1 Engine Tool Set | 1 Strainer, 2 Hose Couplings, 3 Hose Bands, 1 Engine Tool Set | 1 Strainer, 2 Hose Couplings, 3 Hose Bands, 1 Engine Tool Set | |
| Net Weight | 21 kg (46.3 lbs) | 21 kg (46.3 lbs) | 25.2 kg (56.2 lbs) | 28 kg (61.7 lbs) | 27 kg (59.5 lbs) | |
| Gross Weight | 22 kg (48.5 lbs) | 23 kg (50.7 lbs) | 27.2 kg (59.9 lbs) | 30 kg (66.0 lbs) | 30 kg (66.0 lbs) | |
| Dimensions L×W×H (mm) | 483 × 375 × 376 | 483 × 375 × 376 | 504 × 401 × 406 | 525 × 389 × 463 | 525 × 389 × 458 | |
| Packing Unit | 1 | 1 | 1 | 1 | 1 | |
