ปั๊มในตัวประสิทธิภาพสูงเหมาะสำหรับงานที่ต้องการใช้แรงดันปานกลางและสูงปริมาณมาก มีให้เลือกใช้งานทั้ง SU-25V, SU-50V, และรุ่น SU-80V
Powerful Pressure & Enhanced Durability
Model. SU-25V, SU-50V, SU-80V is High-performance self-contained pump ideal for large volumes of medium and high pressure
Feature
Maximum lift 70m (SUR-25V), ideal for sprinklers and irrigation to high places.
High-grade type that is resistant to high pressure and wear.
Five types of diameters from 25 mm to 80 mm are available, so please choose according to the engine, motor, application, and purpose.
| Model | SU-25V | SU-50V | SU-80V | |||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Connection Dia | 25 mm (1″) | 50 mm (2″) | 80 mm (3″) | |||||||
| Connection Thread | Outer Pipe Thread BSP | |||||||||
| Revolution | 4000 rpm | 4500 rpm | 5000 rpm | 3000 rpm | 3600 rpm | 4000 rpm | 3400 rpm | 3800 rpm | 4000 rpm | |
| Total Head | 29 m | 36 m | 45 m | 30 m | 42 m | 53 m | 27 m | 34 m | 38 m | |
| Delivery Volume | 110 L/min | 120 L/min | 130 L/min | 430 L/min | 480 L/min | 500 L/min | 850 L/min | 950 L/min | 1000 L/min | |
| Max. Suction Lift | 7 m | 8 m | 7 m | 8 m | 7 m | 8 m | ||||
| Output | 1.5 kW | 2.2 kW | 2.2 kW | 3.7 kW | 5.5 kW | 5.5 kW | 7.5 kW | 8.6 kW | ||
| Standard Accessories | 1 Strainer, 2 Coupling Sets, 3 Hose Bands | |||||||||
| Net Weight | 7.5 kg | 15 kg | 22 kg | |||||||
| Gross Weight | 8.5 kg | 16 kg | 24 kg | |||||||
| Dimensions L×W×H (mm) | 335 × 195 × 210 | 392 × 250 × 280 | 434 × 277 × 378 | |||||||
| Packing Unit | 1 | |||||||||
