Self- Priming centrifugal pumps KS Model KRIPSOL

KORAL-KS Model

Self- Priming centrifugal pumps for swimming pools

Pump casing in thermoset plastics reinforced with glass fiber.
Lowerable cover screws with stainless steel studs.
Impeller in noryl inserted with 303 stainless steel.
TEFC motor, IP 55 protection, class F.
Possibility of connecting the pump by means of Ø50 or Ø63mm socket unions.
ANSI 1½-2”.
60Hz available
This pump is suitable to be used with sea water.
MECHANICAL SEAL

Specifications data

Type	HP P2	KW P1	Single-phase three-phase					(mm)		Weight (kg.)
			V	A	COND.	V	A	(mm)		Weight (kg.)
			V	A	COND.	V	A	Single-phase	Three-phase	Single-phase	Three-phase
KS33B	0,33	0,45	230	2,45	12	–	–	503	–	11,2	–
KS50B	0,50	0,58	230	3,2	14	230/400	2,45/1,4	550	550	12,5	12,0
KS75B	0,75	0,75	230	3,8	14/16	230/400	3,4/2,05	550	550	13,5	13,0
KS100B	1,00	1,00	230	5	20	230/400	3,6/2,2	550	550	14,0	13,5
KS150B	1,50	1,60	230	7,5	25	230/400	5/2,9	580	580	16,5	16,0
KS200B	2,00	1,92	230	9	30	230/400	6,1/3,5	580	580	17,5	17,0
KS300B	3,00	2,60				230/400	8,3/4,8	620	620	–	22,0

Type	dB (*)	Head in m.
		5	6	8	10	11	12	14	16	18
		Capacity in m³/h
KS33B	54,6	11	8,9	7	4,8	3	–	–	–	–
KS50B	59,6	14,5	12	10	7,5	6,5	5	1	–	–
KS75B	59,6	16	14,5	13,5	11,5	10,2	8,9	5,2	1	–
KS100B	60,8	21,5	19,5	17,5	15,4	14,2	13	10	5,8	1
KS150B	65,6	27,5	25,5	23	21,9	20,8	19,7	16,4	11,8	6,2
KS200B	66	32	29,4	27,8	25,7	24,6	23,5	20,5	17	12
KS300B	66,7	36,5	34,5	32	29,5	28,2	26,9	23,9	20	16,2
