ปั๊มหอยโข่ง LOWARA VM

ปั๊มหอยโข่ง LOWARA VM

The VM series is a modern, robust designed pump offering reliable water supply for most buildings; from family houses up to 10 floor apartment buildings:

• State-of-the-art hydraulics with best-in class efficiency combined with IE3 motors mean the lowest possible operating costs.
• Thick sheet metal casing, high-quality bearings and stainless steel guarantees a long service life.
• High-efficiency hydraulics, motor and thick sheet metal pump body keep the noise level to a minimum.
• Close coupled motor and threaded connections for compact installations.

The VM vertical multistage pump is available in different versions:

• Bare pump
• On/ off system with pressure switch and pressure tank
• Semi constant pressure system with Genyo electronical pump controller
• Constant pressure system with ResiBoost variable speed controller
• Constant pressure system with Teknospeed variable speed controller

SPECIFICATIONS

• Delivery: up to 14 m³/h
• Head: up to 99 m
• Power supply: both single and three-phase 50 and 60 Hz
• Power: from 0,30 kW up to 3 kW
• Maximum operating pressure: 10 bar
• Temperature of pumped liquid: from -10°C to +90°C
